Insulation

Click here to visit our Eastern Cape Branch!!!

fabufill

WHAT NATURE WOULD CHOOSE

  • COST EFFECTIVE
  • NON ALLERGENIC
  • NON ITCH
  • NON FLAMMABLE
  • THERMAL
  • 100% RECYCLABLE
  • 100% ECO & NATURE FRIENDLY
  • FIRE TESTED SANS 428 (B/B1/2)
  • SABS APPROVED
  • B GRADE SPECIALS AVAILABLE
  • THICKNESS FROM 40 MM UP TO 100 MM

Thickness
(mm)
Dimensions
(mm)
R Value
M² k/w
40mm
50mm
75 mm
100 mm
10000 x 1200 x 40
10000 x 1200 x 50
8000 x 1200 x 75
6000 x 1200 x 100
0.94
1.15
1.69
2.20
SD-NEW-BROCHURE-2014-2 1 2



WHY CHOOSE FABUFILL?

  • The ceiling insulation is is manufactured in SA, and Distributed by Sheeting Direct. It has a TYPE 1 classification.
  • The standard width is 1200mm, we can however manufacture 750mm to accommodate the client’s requirements. The density of the material is 10.1kg/m³ which provide residential and commercial properties with the perfect temperatures during both winter and summer.
  • It’s an odourless, non toxic, non allergenic, non itch, user friendly bulk insulation that can easily be installed by the DIY enthusiast
  • It will save you on electricity costs
  • It can be used in residential, commercial and all types of building structures
  • It’s made from recycled PET bottles which makes it environmentally friendly not only to you but to our natural green world that we are desperately trying to save for future generations.
  • 100% Eco- Friendly and is completely recyclable.
  • 100% People and NATURE friendly. It comes in simple and safe, easy to install rolls. It is non allergenic, non irritant and flexible. No special health and safety precautions are required when installing .
  • Will not absorb water and will dry naturally regaining its resistance and density if exposed to water.
  • Fire tested and is safe to use in both residential and commercial applications. It will not contribute to the spread of flame and the product will self extinguish once the heat source is removed.
  • Non Toxic. There are no chemical additives and is completely odourless.
  • Maintenance free. It retains loft and does not degrade over time.
  • Ceiling Insulation is manufactured by Platinum Fibre (Pty) LTD and made from recycled PET Bottles.
  • A type 1 classification.
  • Manufactured in 40mm,50mm,75mm and 100mm.
  • has a density of 10.1kg/m³ which provide the residential and commercial properties with the perfect temperatures during both Winter and Summer.
  • Has a thermal resistance, also known as the ‘R” Value for different sizes (Refer to below box.)
  • R-VALUE –All MATERIALS ARE RATED FOR THEIR PERFORMANCE IN RESTRICTING HEAT TRANSFER. This is expressed as the R- VALUE which is the measure of the materials resistance to heat transfer, alternatively known as thermal resistance. The higher the R- VALUE the greater the insulation effect.



Thermal Resistance

The resistance to heat transfer across a material. It is the mean temperature difference between two defined surfaces of a material under steady state conditions.

Bulk Insulation

Materials of low thermal conductivity, that mainly resists (slows) the transfer of conducted and convected heat, relying on pockets of trapped air within its structure. Its thermal resistance is the same regardless of the direction of heat flow through it and is proportional to its thickness.

Density

The mass of a substance per unit of volume (measured in kg/m³)

National Building Regulations (NBR)

This Regulation “Energy usage in buildings” came into effect on 9 November 2011. All new buildings and extensions have to comply with the new Regulation. All new buildings and building extensions as per the building occupancy classes specified in the regulation will be required to have thermal insulation installed.

  • COST EFFECTIVE
  • NON ALLERGENIC
  • NON ITCH
  • NON FLAMMABLE
  • THERMAL
  • 100% RECYCLABLE
  • 100% ECO & NATURE FRIENDLY
  • FIRE TESTED SANS 428 (B/B1/2)
  • SABS APPROVED



 Click here to download Firelab Insulation Test Report
